Stainless Steel 316 Round Cap – Female BSP Thread Fitting | Fuel Bladder
Stainless Steel 316 Round Cap – Female BSP Thread Fitting | Fuel Bladder
Hurry up, only 5 items left in stock.
Couldn't load pickup availability
Product Details
Product Details
The Stainless Steel 316 Round Cap (Female BSP) securely seals the end of a male-threaded BSP pipe. Designed for fuel bladder systems, this cap offers corrosion resistance, chemical durability, and high-pressure reliability. Acid-cleaned and thread-qualified, it ensures a contaminant-free, leak-proof connection for industrial, marine, and chemical applications
| Specifications | |
|---|---|
| Type: | Screwed Cap |
| Thread: | Female BSP |
| Material: | 316 Stainless Steel |
| Finish: | Polished Stainless Steel |
| Cleanliness: | Acid-cleaned, threads free of swarf and contaminants |
| Compatibility: |
Diesel, petrol, and most fuels |
What's Included
What's Included
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
The Stainless Steel 316 Round Cap (Female BSP) securely seals the end of a male-threaded BSP pipe. Designed for fuel bladder systems, this cap offers corrosion resistance, chemical durability, and high-pressure reliability. Acid-cleaned and thread-qualified, it ensures a contaminant-free, leak-proof connection for industrial, marine, and chemical applications
| Specifications | |
|---|---|
| Type: | Screwed Cap |
| Thread: | Female BSP |
| Material: | 316 Stainless Steel |
| Finish: | Polished Stainless Steel |
| Cleanliness: | Acid-cleaned, threads free of swarf and contaminants |
| Compatibility: |
Diesel, petrol, and most fuels |
Australian Standard BSP Fitting Size Chart
| Size Imperial (inch) | Male Fitting EndMetric (mm) | Male/Female Outer(OD) / Inner Dia.(ID) (mm) | Threads Per Inch |
Actual Barb EndOuter Diameter (mm) |
|---|---|---|---|---|
| 3/8″ | 10 | 16.7 / 10.3 | 19 | 10 |
| 1/2″ | 13 | 20.9 / 13.2 | 14 | 13 |
| 3/4″ | 19 | 26.4 / 19.0 | 14 | 19 |
| 1″ | 25 | 33.2 / 25.0 | 11 | 25 |
| 1 1/4″ | 33 | 41.9 / 32.9 | 11 | 32 |
| 1 1/2″ | 38 | 47.8 / 38.6 | 11 | 38 |
| 2″ | 50 | 60.3 / 50.0 | 11 | 51 |
| 2 1/2" | 65 | 75.2 / 66.0 | 11 | 64 |
Technical Definitions
- Size: Size designated to match the ID of Fitting in inches.
-
Male / Female Fitting (OD) (Outer / Inner Diameter):
- Male OD: The actual measurement across the outside of the male threads.
- Female ID: The actual measurement of the inside diameter of a female threaded port
- Threads Per Inch (TPI): The thread pitch, representing the number of individual thread peaks found within a one-inch (25.4mm) section.
- Actual Barb End: The outer diameter of the ribbed section. This should match the Internal Diameter (ID) of your hose.
