316 Stainless Steel Tank Outlet BSP Skin Fitting – Male Bulkhead
316 Stainless Steel Tank Outlet BSP Skin Fitting – Male Bulkhead
Available in stock (100)
Couldn't load pickup availability
Product Details
Product Details
Heavy Duty Bulkhead Tank Fitting with Backnut for Water & Fuel Bladders
Ensure a strong, leak-free connection with this 316 Stainless Steel Skin Fitting BSP Male Bulkhead, designed for durability in harsh and demanding environments. Built from marine-grade 316 stainless steel, this fitting offers excellent corrosion resistance, making it ideal for use in water, fuel, and chemical applications.
The male BSP thread with backnut design allows for secure through-wall installation on tanks, bladders, and containers. Whether you're working with water storage systems, fuel bladders, marine plumbing, or industrial tanks, this fitting provides a reliable and long-lasting solution.
Perfect for both professional and DIY setups, it integrates easily with standard BSP fittings, valves, and hoses.
| Specifications | |
|---|---|
| Product Type | Skin Fitting / Bulkhead Fitting |
| Material | 316 Stainless Steel |
| Thread Type | BSP (British Standard Pipe) |
| Thread | Male |
| Mounting Type | Bulkhead (Through Wall) |
| Included | Backnut |
| Corrosion Resistance | Yes – Marine Grade |
| Application | Water, Fuel, Chemical Systems |
What's Included
What's Included
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Heavy Duty Bulkhead Tank Fitting with Backnut for Water & Fuel Bladders
Ensure a strong, leak-free connection with this 316 Stainless Steel Skin Fitting BSP Male Bulkhead, designed for durability in harsh and demanding environments. Built from marine-grade 316 stainless steel, this fitting offers excellent corrosion resistance, making it ideal for use in water, fuel, and chemical applications.
The male BSP thread with backnut design allows for secure through-wall installation on tanks, bladders, and containers. Whether you're working with water storage systems, fuel bladders, marine plumbing, or industrial tanks, this fitting provides a reliable and long-lasting solution.
Perfect for both professional and DIY setups, it integrates easily with standard BSP fittings, valves, and hoses.
| Specifications | |
|---|---|
| Product Type | Skin Fitting / Bulkhead Fitting |
| Material | 316 Stainless Steel |
| Thread Type | BSP (British Standard Pipe) |
| Thread | Male |
| Mounting Type | Bulkhead (Through Wall) |
| Included | Backnut |
| Corrosion Resistance | Yes – Marine Grade |
| Application | Water, Fuel, Chemical Systems |
Australian Standard BSP Fitting Size Chart
| Size Imperial (inch) | Male Fitting EndMetric (mm) | Male/Female Outer(OD) / Inner Dia.(ID) (mm) | Threads Per Inch |
Actual Barb EndOuter Diameter (mm) |
|---|---|---|---|---|
| 3/8″ | 10 | 16.7 / 10.3 | 19 | 10 |
| 1/2″ | 13 | 20.9 / 13.2 | 14 | 13 |
| 3/4″ | 19 | 26.4 / 19.0 | 14 | 19 |
| 1″ | 25 | 33.2 / 25.0 | 11 | 25 |
| 1 1/4″ | 33 | 41.9 / 32.9 | 11 | 32 |
| 1 1/2″ | 38 | 47.8 / 38.6 | 11 | 38 |
| 2″ | 50 | 60.3 / 50.0 | 11 | 51 |
| 2 1/2" | 65 | 75.2 / 66.0 | 11 | 64 |
Technical Definitions
- Size: Size designated to match the ID of Fitting in inches.
-
Male / Female Fitting (OD) (Outer / Inner Diameter):
- Male OD: The actual measurement across the outside of the male threads.
- Female ID: The actual measurement of the inside diameter of a female threaded port
- Threads Per Inch (TPI): The thread pitch, representing the number of individual thread peaks found within a one-inch (25.4mm) section.
- Actual Barb End: The outer diameter of the ribbed section. This should match the Internal Diameter (ID) of your hose.
